Infused dried fruits

PIGO infused dried fruits systems are concepted to create a “High Added Value Fruit” production plant, which contains dozens of small innovations and a few large improvements for a more reliable system, all together improving natural fruit characteristics.
PIGO is also providing CONTINUOUS INFUSION TECHNOLOGY and KNOW-HOW to our clients.
PIGO srl has established itself as a world-class leader in the design and manufacture of high technology freezing and drying equipment, as well as fruit and vegetable entire processing lines.

Modern consumer is more and more oriented to the natural products and products which natural properties are improved. At the same time it is necessary to improve the preservation ability and expand the use possibilities – shelf life. Infused dried fruit meets all the above criteria. Fresh fruit, especially forest fruits, which has exceptional organoleptic characteristics, receives new qualities with infusion process, for example improvement of the natural characteristics of the fruit. Infused dried fruits preservation is possible without special packaging and storage conditions.Finally, in the infused dried fruits it can be introduced also other useful and important to the health substances, such as microelements, etc.


The manufacturing process of infused dried fruits is based on the natural processes of membrane diffusion, that is trough the membrane - the cells membrane of the fruits diffuse the material aiming to equalize the concentration.

Unlike the classical process of fruit drying, the infused dried fruits process mostly preserves the original shape and color of fresh fruits.
In this unique way can be obtained the dried raspberry, cherry and other fruit, with a high content of healthy fruit sugar (fructose), preserving as much as possible the form (without the deformation of the conventional drying), which is not possible with any other technological process (besides freeze drying).
A very important feature of this process is that during the process of infusion disaccharides of the sugar syrup turn into healthy, natural monosaccharides, or fruit sugar - fructose, which improves the natural qualities of the fruit.
The final product – INFUSED DRIED FRUIT – is not SWEETENED. It containes NO ADED SUGAR, but ply natural healthy FRUTCTOSE – fruit sugar contained naturally by fruit. It is NATURAL BEST, containing up to 65 % of fructose.

Basic steps of Infused Dried Fruit Process:
•Solution preparation for the fruit pre-treatment
•Fruit treatment with stabilization solution
•Preparation of the solution for infusion
•Infusion process
•Infusion solution recycling and regeneration
•Surface washing of infused fruits
•Application of oily materials to prevent clumping of the finished fruits


•All containers (sugar solution and product containers) are entirely made in stainless steel;
Mixer for the eparation of stabilisation solutions
•The mixer is positioned on the wheelchair and is equipped with a mixer and pomp
Installation for sugar dissolving
•system for dispensing sugar, recirculation syrup pump, Heat correction / heating, stabilisation solution or depleted syrup

The finishing line that consisting in device for emptying containers, Collecting container for depleted syrup and a pump for pumping syrup to a large container, washing conveyor, Air blower to remove drops, Drum with spray system for spraying oil, Device for measuring products on the pan if the drying is performed in a batch oven or system to add products to spiral belt.

Advantages of Infused Dried Fruits:
•It minimizes the effect of temperature on food quality and preserves the wholeness of the food, as no high temperature/phase change is required in the process
•Mild heat treatment favours colour and flavour retention resulting in the product having superior organoleptic characteristics. It is more when sugar syrup is used as osmotic agent
•Acid removal and sugar uptake by fruits modifies the composition and improves the taste and acceptability which is called candying effect
•It protects against the structural collapse of the product during subsequent drying. It helps to retain the shape of the dehydrated products
•It improves the texture and rehydration properties
•Constant immersion of product in osmotic agents avoids the O2 exposure, so the product retains better colour
